Thoracoscopic right S6 sleeve segmentectomy for squamous-cell carcinoma arising from the B6 central bronchus
Surgical Technique

Thoracoscopic right S6 sleeve segmentectomy for squamous-cell carcinoma arising from the B6 central bronchus

Takuya Nagashima1, Kenji Inui2, Kenji Kanno2, Hiroyuki Ito1, Haruhiko Nakayama1

1Department of Thoracic Surgery, Kanagawa Cancer Center, Yokohama, Japan; 2Respiratory Disease Center, Yokohama City University Medical Center, Yokohama, Japan

Correspondence to: Takuya Nagashima, MD. Department of Thoracic Surgery, Kanagawa Cancer Center, 2-3-2, Nakao Asahi-ku, Yokohama 241-8515, Japan. Email: naga16@kcch.jp.

Abstract: We describe a patient with low respiratory function who underwent thoracoscopic sleeve segmentectomy to preserve lung function as much as possible. The patient had already used home oxygen therapy because of chronic obstructive lung disease. There was a squamous-cell carcinoma at inlet of right B6 bronchus, and cT1aN0M0 disease was diagnosed. Because respiratory function was poor, right S6 segmentectomy was scheduled. Moreover, to preserve the respiratory muscles as much as possible, a thoracoscopic approach was selected. We performed S6 sleeve segmentectomy, and sutured the lower bronchus and basal bronchus. There were some limitations in handling needles during thoracoscopy. To resolve these difficulties, we devised two techniques. One was to suture the bronchus with continuous sutures on the mediastinal side and simple interrupted sutures on the other side. The other was to create a working space for handling the needles to avoid entanglement of the sutures. These techniques allowed us to suture the bronchi relatively easily.

Keywords: Thoracoscopic surgery; bronchoplasty; sleeve segmentectomy; lung cancer


Submitted Jul 05, 2017. Accepted for publication Jan 15, 2018.

doi: 10.21037/jtd.2018.01.93


Introduction

Complete video-assisted thoracoscopic surgery is a widely used minimally invasive procedure for the management of lung cancer. However, the indication is most often limited to early lung cancer. Because many patients with advanced lung cancer require bronchoplasty, thoracoscopic surgery is generally not indicated. Segmentectomy for lung cancer was performed in 4,143 patients in 2014 according to the annual report of the Japanese Association for Thoracoscopic Surgery. However, sleeve segmentectomy was done in only 16 patients (1). Bronchoplasty is technically difficult to perform via a thoracoscopic approach because the insertion angle of the needle holder and the manipulation of the needle are generally restricted. Open surgery is therefore often performed. We describe a patient in whom bronchoplasty could be relatively easily performed via a thoracoscopic approach by using improved methods for suturing the bronchi and handling suture material in the thoracic cavity, leading to the preservation of respiratory function.


Clinical summary

The patient was a 74-year-old man who had a past history of chronic obstructive pulmonary disease (COPD) and received home oxygen therapy (2 L). Computed tomographic examinations during the follow-up revealed an 8-mm nodular shadow in the B6 bronchus of the right lower lobe. It obstructed the B6a and B6b bronchi. The peripheral margin was not seen. A bronchoscopic biopsy revealed squamous-cell cancer (Figure 1A), with no evidence of distant metastasis. Clinical T1aN0M0 disease was thus diagnosed according to the 7th edition of the American Joint Committee on lung cancer staging manual. On preoperative respiratory-function tests, the forced expiratory volume in 1 second (FEV1) was 2,330 mL (FEV1%, 62%), and the percent predicted diffusing capacity of the lung for carbon monoxide (DLCO%) was 31.7%. To preserve respiratory function and respiratory muscles, we performed a thoracoscopic right S6 sleeve segmentectomy with hilar lymph node dissection.

Figure 1 Bronchoscopic findings. (A) There was a nodular lesion at the inlet of the right B6 bronchus (black arrow) before surgery; (B) the patency of both the middle bronchus and basal bronchus were good 1 month after surgery. M, middle lower bronchus.

The postoperative course was good. On postoperative day 3, the oxygen dose was 2 L, which was the same as that before surgery. On postoperative day 9, the patient was discharged from the hospital. There has been no recurrence as of 6 months after surgery. On respiratory function tests performed 6 months after surgery, the FEV1 was 1.94 L, which was clearly better than the expected FEV1 (1.66 L) after right lower lobectomy. Bronchoscopy 1.5 months after surgery revealed patency of the peripheral bronchi (Figure 1B).


Operative technique

The patient was placed in lateral position. The operator stood on the dorsal side of the patient. A 3-cm skin incision was made along the sixth costal midaxillary line, and an Alexis® Wound Retractor XXS (Applied Medical, Rancho Santa Margarita, CA, USA) was placed into the incision to serve as an aperture for the operator’s right hand. A 7-mm trocar was inserted into the fifth costal posterior axillary line to serve as an aperture for the operator’s left hand. A 10-mm trocar was inserted into the fourth costal anterior axillary line. A 10-mm camera and an oblique-viewing endoscope (30 degrees) were used. A 15-mm skin incision was made along the fifth costal anterior axillary line. A Lap-protector Minimini® (Hakko Medical, Tokyo, Japan) was inserted to serve as an aperture for the assistant’s hand (Figure 2). A monitor with two screens was used. One screen was rotated at the time of surgery.

Figure 2 A picture showing the position of the incision. ① A 3-cm incision for the operator’s right hand; ② a 7-mm incision for the operator’s left hand; ③ a 10-mm incision for the thoracoscope; ④ a 15-mm incision for the assistant.

Similar to the procedure for conventional S6 segmentectomy, the superior segmental vein of the lower lobe (V6), the superior segmental artery of the lower lobe (A6) and segmental plane were dissected, and only the superior segment of the lower lobe of the lung (B6) was left intact. The #11 and #12 lymph nodes were dissected. There was no metastasis. To relax tension on the bronchial anastomosis, the pulmonary ligament was dissected.

A scalpel and endoscopic scissors were used to perform sleeve segmentectomy of the lower bronchus lobe of the lung, and the superior segment of the right lower lobe was removed. The bronchial resection margin was confirmed to be pathologically negative in a frozen section, and the distance between the tumor and the incision margin was 5mm. To preserve the middle bronchial lobe, the central bronchial margin was dissected at a slightly oblique angle to the long axis of the bronchus. The peripheral bronchus was transected nearly vertically to the bronchial axis.

To facilitate suturing, the bronchus was closed using a combination of continuous sutures and simple interrupted sutures. The surgical sutures used were 4-0 Prolene® RB-1 (Ethicon, Somerville, NJ, USA). The mediastinal part of the bronchus was continuously sutured. The remaining part was closed with 9 stitches applied from the dorsal side to the ventral side of the mediastinum. These sutures were placed outside of the thoracic cavity via an assistant aperture without being tied and were grasped by forceps. To prevent entanglement of the sutures in the thoracic cavity, a small piece of Naruke Solacotton® (KenzMedico, Saitama, Japan) was inserted from an assistant aperture, and the sutures were pulled towards the dorsal and caudal sides of the mediastinum in the thoracic cavity (Figure 3). This step allowed a working space to be secured for further handling of the sutures. The sutures were ligated from the ventral side towards the dorsal side of the mediastinum.

Figure 3 Intraoperative image. Sutures that had already been handled were retracted posteriorly and caudally (arrow). This created a working space (dotted round) to handle the next needle. RML, right middle lobe; RUL, right upper lobe; Br, bronchus; seg, segment.

After suturing, the airway pressure was increased to 30 cmH2O to perform aerial fistula testing. No aerial fistula was observed at the bronchial anastomosis. A pericardial fat pad was inserted into the space between the anastomosis and the pulmonary arteries. The operation time was 191 minutes, and the bleeding volume was 5 mL (Figure 4).

Figure 4 The procedure of thoracoscopic sleeve segmentectomy (2). Available online: http://asvidett.amegroups.com/article/view/22887

Comments

Generally, sleeve segmentectomy is performed only in patients with decreased pulmonary function in whom the preservation of pulmonary function is a priority. On the other hand, thoracoscopic surgery has been reported to minimally impair the respiratory musculature and to cause a particularly low decrease in respiratory function during the early postoperative period (3). Our patient was receiving home oxygen therapy before surgery, making it imperative to minimize loss of respiratory function. Thoracoscopic sleeve segmentectomy was therefore selected as the procedure of choice. Although radiotherapy was also considered, such treatment carried the risk of causing radiation pneumonitis. We decided to perform surgery, which has a higher probability of leading to radical cure. Okada et al. performed sleeve segmentectomy in a series of 16 patients with lung cancer and reported that no patient had recurrence and stressed the importance of the histopathological evaluation of the resection margins during surgery (4). We thus intraoperatively evaluated the resection margins and believe that there is a good chance of achieving cure. Although some studies reported that the false negative rate of the bronchial margin in frozen sections was1.9–50% (5), the margin in our case was negative in both the frozen section and final histological examinations.

In our study, we modified two points of the technique used to perform bronchial suturing. First, we used a hybrid technique that combined continuous sutures with simple interrupted sutures. As reported by Berthet et al., in this technique the mediastinum is closed with continuous sutures, and other parts are closed with simple interrupted sutures (6). Continuous sutures have been reported to be relatively easy to manage even during complete video-assisted thoracoscopy. However, if suturing and the final ligation are incorrectly performed, the entire procedure must be repeated. Therefore, performing this technique by thoracoscopic surgery carries a high risk. In contrast, the use of only simple interrupted sutures not only increases the number of ligations, but also causes difficulty in suture management, prolonging the operation time. However, resuturing of simple interrupted sutures is relatively easy. We therefore combined these two methods. Our method was particularly useful for performing thoracoscopic surgery, associated with difficulty in stitching and suturing. Li et al. performed video-assisted thoracoscopic sleeve lobectomy with bronchoplasty using this method in 11 patients and found that the operation time was similar to that of open surgery and allowed the incidence of complications to be decreased (7).

Second, to manage the sutures, we pulled the completed sutures dorsally and caudally in the thoracic cavity. Because thoracoscopic surgery requires only a small incision, sutures that run parallel in the region from the suture site to the wound are apt to entangle. By deploying the sutures placed in the bronchi toward the dorsal side of the thoracic cavity, a working space was created on the abdominal side, which was useful for preventing suture entanglement. Moreover, because stitching was basically performed from the caudal side toward the cranial side, it was useful to deploy the sutures in a caudal direction so that the newly placed sutures would not come in contact with the sutures that had already been placed on the cranial side.

Thoracoscopic sleeve segmentectomy is technically challenging. However, this procedure may be useful for enhancing the curability of lung cancer and the preservation of respiratory function in appropriately selected patients who undergo refined surgical techniques.


Acknowledgements

None.


Footnote

Conflicts of Interest: The authors have no conflicts of interest to declare.

Informed Consent: Written informed consent was obtained from the patient for publication of this manuscript and any accompanying images.


References

  1. Committee for Scientific Affairs, The Japanese Association for Thoracic Surgery, Masuda M, et al. Thoracic and cardiovascular surgery in Japan during 2014: Annual report by The Japanese Association for Thoracic Surgery. Gen Thorac Cardiovasc Surg 2016;64:665-97. [Crossref] [PubMed]
  2. Nagashima T, Inui K, Kanno K, et al. The procedure of thoracoscopic sleeve segmentectomy. Asvide 2018;5;089. Available online: http://asvidett.amegroups.com/article/view/22887
  3. Endoh H, Tanaka S, Yajima T, et al. Pulmonary function after pulmonary resection by posterior thoracotomy, anterior thoracotomy or video-assisted surgery. Eur J Cardiothorac Surg 2010;37:1209-14. [Crossref] [PubMed]
  4. Okada M, Nishio W, Sakamoto T, et al. Sleeve segmentectomy for non-small cell lung carcinoma. J Thorac Cardiovasc Surg 2004;128:420-4. [Crossref] [PubMed]
  5. Vallières E, Van Houtte P, Travis WD, et al. Carcinoma in situ at the bronchial resection margin: a review. J Thorac Oncol 2011;6:1617-23. [Crossref] [PubMed]
  6. Berthet JP, Paradela M, Jimenez MJ, et al. Extended sleeve lobectomy: one more step toward avoiding pneumonectomy in centrally located lung cancer. Ann Thorac Surg 2013;96:1988-97. [Crossref] [PubMed]
  7. Li Y, Wang J. Video-assisted thoracoscopic surgery sleeve lobectomy with bronchoplasty. World J Surg 2013;37:1661-5. [Crossref] [PubMed]
Cite this article as: Nagashima T, Inui K, Kanno K, Ito H, Nakayama H. Thoracoscopic right S6 sleeve segmentectomy for squamous-cell carcinoma arising from the B6 central bronchus. J Thorac Dis 2018;10(2):1077-1080. doi: 10.21037/jtd.2018.01.93
