Blunt thoracic aortic injury (BTAI) is a leading cause of death, second only to head injury in patients with blunt trauma (1,2). Despite its low incidence, accounting for about 1.5% to 2.0% of chest trauma, BTAI is considered a life-threatening condition (3,4). The exact mechanisms underlying BTAI have been studied extensively, and there are 2 leading theories. The most commonly described physical mechanism is rapid deceleration with the application of either anteroposterior or lateral forces upon the relatively mobile ascending thoracic aorta, with shearing forces predominantly at the aortic isthmus. The other major physical theory underlying BTAI is direct penetrating injury from rib and thoracic vertebral fractures (5-7). About 80% of patients with BTAI die before admission, and the in-hospital mortality rate is as high as 50% (5,8). BTAI can be detected easily by computed tomography (CT) of the chest or great vessel post-trauma, with a diagnostic accuracy of up to 100% (9). However, the specific type known as delayed blunt thoracic aortic injury (DBTAI) is a notable exception. To date, far too little attention has been paid to DBTAIs resulting from rib fractures (RFs). Although the condition is uncommon, a missed diagnosis can lead to fatal bleeding complications. Early diagnosis and timely treatment are crucial for preventing such adverse outcomes. Considering the possibility of continuous displacement in the short term (10), theoretically speaking, fresh fractures in the left posterior ribs near the descending aorta entail the risk of aortic injuries, despite the fact that the number of such reported complications are on the scarce side. Which kind of patients should be prioritized? Patients with severe RFs are frequently associated with other injuries. How should surgical treatment be performed effectively? We present the following article in accordance with the AME Case Series reporting checklist (available at https://jtd.amegroups.com/article/view/10.21037/jtd-22-1359/rc).
The study was conducted in accordance with the Declaration of Helsinki (as revised in 2013). The study was approved by the ethics committee of Shanghai Sixth People’s Hospital (No. 2020-KY-034). Individual consent for this retrospective analysis was waived. Clinical data were collected from 7 patients who received treatment at the Shanghai Jiao Tong University Affiliated Sixth People’s Hospital due to closed RF-induced delayed thoracic aortic injury (DTAI) from June 2015 through June 2020. There were 5 male and 2 female patients aged from 43 to 64 years. The injuries involved the following mechanisms: falls from height (n=3), motor vehicle accidents (n=2), falls from a bicycle (n=2), and getting hit by a heavy object (n=1). RFs with dislocation and injuries to the aorta were absent on the chest CT on the day of injury (Figure 1A,1B). Findings on the chest CT at 1–4 days post-injury indicated possible TAI caused by RFs. The RF broken ends causing aortic injury were all found in the lateral erector spinae, and >3 fractured ribs were present in all these patients. There were left RFs (n=2), left RFs with spleen rupture (n=2), bilateral RFs (n=1), left rib and leg fractures (n=1), and left RFs with hip dislocation and lumbar spine fractures (n=1). The thoracic aorta was either directly injured by left RF broken ends (n=5) or by free bone fragments (n=2). The posterior ribs that injured the aorta were the 6th (n=1), 7th (n=3), 8th (n=2), and 5th–8th (n=1) posterior ribs.
The surgical procedures are summarized as follows: A patient in a state of shock upon admission underwent emergency exploratory laparotomy and splenectomy. At 4 days post-surgery, the free bone fragments of the 7th left rib were found to have potentially injured the thoracic aorta (Figure 2). At 5 days post-injury, the patient received open reduction and thoracoscopic removal of free bone fragments. In a case of left RFs with spleen rupture, the patient was transferred to our hospital after conservative treatment. As the CT scan upon admission indicated possible TAI (Figure 3), the patient underwent emergency exploratory thoracotomy, surgical fixation, and aortic repair simultaneously. As for the 2 cases of left RFs with lumbar spine and leg fractures, exploratory thoracotomy was performed following surgical fixation. The left and bilateral RF cases received surgical fixation of the fractured ribs on the left side and exploratory thoracotomy. The intraoperative exploration revealed that 6 patients had hematomas in the aortic tunica adventitia, and 1 had a ruptured aortic tunica adventitia and elastic layers. Details are presented in Table 1. The literature review covered 8 cases of RF-induced descending aortic injury, of which 3 were caused by free bone fragments and 5 by broken ends. The treatment methods were resection of broken ends and removal of free bone fragments with atraumatic sutures (n=8). Details of these cases are listed in Table 2.
|Gender||Age (year)||Injury factor||Time from injury to CT finding that ribs were closely related to the aorta (d)||Left-sided rib fractures||Posterior rib of the injured aorta||Complicated injury||Surgery||Aortic injury||Hospital stay (d)|
|Male||62||Fall from height||4||3rd–9th rib fractures||7th posterior rib||Splenic rupture||Staged surgery, splenectomy first||Adventitial hematoma||9|
|Male||63||Fall from height||3||3rd–11th rib fractures||6th posterior rib||Splenic rupture||Synchronous surgery, rib fracture fixation and aortic repair first||Rupture of the aortic adventitia and elastic layer||21|
|Male||51||Motor vehicle accident||2||2nd–11th rib fractures||7th posterior rib||Fracture of the 2nd lumbar vertebra||Staged surgery, rib fracture fixation and thoracoscopic exploration first||Adventitial hematoma||7|
|Male||58||Fall from a bicycle||3||2nd–10th rib fractures||8th posterior rib||No||Rib fracture fixation and thoracoscopic exploration||Adventitial hematoma||3|
|Male||43||Motor vehicle accident||3||2nd–11th rib fractures||8th posterior rib||Left lower limb fracture, left hip dislocation||Staged surgery, rib fracture fixation and thoracoscopic exploration first||Adventitial hematoma||14|
|Female||54||Fall from height||1||3rd–10th rib fractures||5th–8th posterior ribs||No||Rib fracture fixation and thoracoscopic exploration||Adventitial hematoma||14|
|Female||64||Heavy pound||2||1st–11th rib fractures||7th posterior rib||Fractures of the right 2nd-8th ribs||Left rib fracture fixation, thoracoscopic exploration and conservative treatment of the right rib first||Adventitial hematoma||4|
CT, computed tomography.
|Case No.||Sex||Age (years)||Fractured left ribs||Fractured ribs causing TAI||Surgical procedure(s)||Author(s)||Year of publication|
|1||Female||24||9–10||Fracture ends of the 10th left rib||Resection of the 10th left rib + adventitial repair with pleura||Kabiri et al. (11)||2007|
|2||Male||57||6–10||Fracture ends of the 6th and 7th left ribs||Fracture end repair + adventitial repair||Yanagawa et al. (12)||2008|
|3||Male||87||8–9||Free bone fragments of the 8th left rib||Removal of free bone fragments + direct adventitial repair||Bruno et al. (13)||2009|
|4||Female||43||Unknown||Free bone fragments of the 5th left rib||Resection of free bone fragments + aortic repair||Carter et al. (14)||2011|
|5||Male||63||5–11||Fracture ends of the 7th left rib||Resection of fracture ends + adventitial repair||Kitamura et al. (3)||2012|
|6||Female||55||3–8||Free bone fragments of the 7th left rib||Death||Kano et al. (15)||2014|
|7||Female||34||4–8||Fracture ends of the 4th–6th left ribs||Resection of the 4th–8th left ribs + total aortic repair||Xie et al. (16)||2019|
|8||Male||66||8–11||Fracture ends of the 10th left rib||Resection of fracture ends of the 10th left rib + adventitial repair|
TAI, thoracic aortic injury.
There was no perioperative death, and the length of stay in our hospital was 3 to 21 days. In the case of left RFs with spleen rupture, acute renal failure and secondary intra-abdominal infection occurred after overlapping emergency surgery. Conservative treatment was administered accordingly, and the patient was discharged after cure. No perioperative complications were observed in other patients. The pre-discharge chest CT scans showed that the fractured ribs were stabilized after internal fixation (Figure 4). According to the follow-up CT scans at 6 months post-discharge, the fracture ends were in place, without any signs of displacement or abnormalities at the site of the thoracic aorta.
BTAI is a clinically rare but fatal condition (17). RFs serve as a chief risk factor for BTAI (18,19). The retrospective study by Choi et al. showed that RFs contributed to approximately 22.9% of all closed TAI cases (20). The diagnosis of this TAI largely depends on the initial CT and clinical manifestations such as a hemorrhagic shock after injury. For acute BTAI, only about 20% of patients can make it to the hospital, and more than 40% die during their hospital stay (21).
In addition to acute injury to the aorta, RFs can result in delayed TAI, which has an insidious onset and escapes the initial imaging tests after injury. The exact mechanism of this injury is not fully understood. It is inferred that there is a small clot covering the perforated aorta, and the unintended removal of the clot leads to massive hemorrhage (22), or RF displacement due to movement penetrates the aorta and results in BTAI (13,14). Another possible explanation relates to nursing procedures (such as turning over the body and tapping the back) or vigorous passive movement during patient transfers. From the cases reported by previously published studies (14,16,22) and our hospital, it is evident that TAI is more likely in patients with ≥4 fractured ribs or multiple fractures in a single rib, of which the broken ends exist in the lateral erector spinae. This may be explained by the loss of local chest wall stability after multiple RFs that entails a risk of displacement. If a rib is broken in multiple places, the bone fragments will become free-floating and prone to penetrate the thoracic cavity. RFs beyond the lateral erector spinae are distant from the aorta and thus can hardly affect the aorta even if displacement occurs. Notably, the present study suggested that fractures of the 10th rib could induce TAI, whilst previous study reached different conclusions (23). Timely diagnosis plays a pivotal role in the treatment of delayed TAI. Therefore, it is recommended that patients receive active surgical intervention if fractures of the 4th–10th left ribs, including the bicortical ones, are present with such important factors.
Although the indications for RF internal fixation have been a controversial and disputed subject (24), it is generally accepted that patients with >3 fractured ribs should receive internal fixation (25). As far as RFs are concerned, the most important treatment principle is to prevent or minimize the risk of complications (26). Considering the potentially fatal consequences, surgical intervention should be undertaken early after diagnosis. Non-RF-induced closed TAI is associated with shearing forces, abrupt deceleration, and acute changes in intravascular pressure. These BTAI cases typically involve the aortic isthmus (6,7). By contrast, RF-induced TAI predominantly affects the aorta adjacent to the broken ends of RFs or surrounded by free bone fragments (15). For TAI caused by post-fracture free bone fragments, some researchers propose treatment plans centered on the removal of free bone fragments (14,27). However, given the lack of plates to stabilize the floating ribs, such plans cannot eliminate the risk of secondary TAI unless adequate resection margins are achieved (28). Notably, excessive resection can result in the loss of mineral elements from the affected ribs. In most cases, the broken ends of fractured posterior ribs contributing to TAI reside in the inside of lateral erector spinae, which can be partially resected or used as a strut to achieve internal fixation if they adjoin the transverse process of the corresponding vertebra (29). In patients with transverse process fractures who have been treated by our hospital and followed up for over a year, the steel plates have not become loose or significantly affected their daily activities even though further follow-ups are needed to assess the long-term outcomes. When a patient needs overlapping emergency surgery for spleen rupture and TAI, under which circumstances saving the patient’s life is always the top priority, the TAI should be repaired first to avoid displacement of the fracture ends due to traction of the left chest wall when handling the intra-abdominal organs to expose an incision. Otherwise, it can lead to fatal aortic rupture and massive hemorrhage. Vital signs require close monitoring throughout the operation, and the time of thoracic operation should be minimized by treating TAI and fixing displaced ribs as quickly as possible. Thoracoscopy is recommended for these procedures to look at the operation field from different angles and ensure the safe removal of free bone fragments.
The present study has its limitations. First, it is limited by the modest sample size. Only 7 cases have been reported by our hospital because the condition has a low incidence. The overall sample size remains small even though other reported cases have been included for multi-center retrospective analysis. Second, the absence of a control group makes it impossible to provide statistical evidence for our conclusions and underpins the need for further validation of the study results with more cases.
For patients with bicortical and more severe fractures of the 4th–10th left posterior ribs, active surgical intervention is recommended if they have the following important factors for delayed TAI: there are ≥4 fractured ribs or a single rib fractured in multiple locations; or the fracture ends are in the inside of the lateral erector spinae. Surgical procedures are needed to fix floating ribs, remove free bone fragments, and stabilize the chest wall, while exploratory thoracoscopy can help assess the severity of TAI and develop treatment plans accordingly.
